GWF4 Wireless Footswitch

A wireless footswitch made for Mooer intelligent systems such as GTRS guitars and Prime P1! Just by connecting your GTRS guitar via Bluetooth, you can set various presets and tone controls from the app, and share presets from the cloud.

Features

• Connect to GTRS guitar, easy to change preset and tone settings while playing
• Tap tempo settings
• 2.4G Wireless connection
• Chargeable Built-in battery

Control mode 1

Change preset bank : Pressing foot switches A and B or C and D at the same time switches preset banks. When you switch preset banks, the back number will flash, and you can select a preset within the bank by pressing the footswitch.
Change Preset: Press the footswitch to change the preset within the current bank. The LED for each footswitch indicates the current preset, and the LED display shows the current preset name.

Control mode 2

Press foot switch A to switch from preset 9D to 0A, and press foot switch B to switch from preset 0A to 9D. The LED display will show the currently selected preset and the footswitch LED will turn off.
CTRL: Footswitches C and D become CTRL functions. In this mode, the footswitch LED will display the effect status. When assigned a TAP control, the footswitch LED will flash once the footswitch is pressed.

Tuner

Long press the control knob on the GTRS guitar or press the switch assigned to the tuner in GWF4 to start the tuner. In tuner mode, all footswitch LEDs are turned off and the current pitch is displayed on the LED display. The pitch is displayed on the left side of the display. When the right display is clockwise, it means the current pitch is sharp, and counterclockwise means it is flat. When the display on the right side of the display stops rotating, you have tuned to the correct pitch.

Low battery alert

When the battery level is low, the footswitch LED will flash.
